Glosmetru portabil de precizie
Model Elcometer 480

Aparat multiparametric pentru determinarea luciului

Triple Angle Glossmeter


produsul poate fi achizitionat si prin SEAP


Solicit oferta personalizata »

Imbina cele mai noi tehnici recunoscute la nivel mondial, fiind posibile realizarea masurarii fiabile, determinarea cu preciziei a luciului, % reflexiei si incetesorii (Haze) pentru orice material, inclusiv vopsea, plastic, ceramica sau metal.datorita tehnologiei cu leduri masoara cu precizie pana la 3 unghiuri in acelasi timp, avand o viteza de 10 inregistrari pe secunda.
Inregistrarile pot fi transferate instantaneu pe PC, Iphone, Android sau alte dispozitive mobile, cu ajutorul functiei USB sau Bluetooh.Folosind software ElcoMaster, pot fi generate rapid rapoarte profesionale pentru luciu si alte masuratori.
Inregistrarile alternative ale luciului pot fi combinate cu alti parametri cheie de masurare, cum ar fi : grosimea stratului, aderenta si diagrama de temperatura a cuptorului – cu acelasi pachet software.
Elcometer 480 poate fi disponibil cu un singur unghi de 600 pentru masurarea luciului sau poate fi disponibil cu doua sau trei unghiuri.

Standarde aplicabile
AS/NZS 1580.602.2, ASTM C584, ASTM C523, ASTM D523, ASTM D1455, ASTM D2457, ASTM D4039, ASTM D4449, ASTM D5767, ASTM E430, ASTM E2387, BS 3900 D5, DIN 67530, ECCA T2, EN 12373-11, EN 13523-2, ISO 7668, ISO 2813, ISO 13803, JIS K 5600-4-7, JIS Z 8741, TAPPI T 653 (20°)

Acuratete si Repetabilitate
Electronica avansata si designul optic superior combina masuratorile precise, repetabile si fiabile cu industria de lider acord inter-instrument pe intrega sa gama 0 – 2,000 GU.

date tehnice

Domeniu 0-10GU 10-100GU 100-2000GU
Repetabilitate ±0.1GU ±0.2GU ±0.2%
Reproductibilitate ±0.2GU ±0.5GU ±0.5%

Afisaj: 2.4"(6cm) QVGA color TFT display, 320 x 240 pixels
Alimentare: USB (via PC) sau 2 bateri x AA (~50000 masurari)
Dimensiuni de masurare: 20°: 10 x 10mm; 60°: 8 x 16mm; 85°: 4 x 55mm
Domeniu de masurare: 20°: 0 - 2,000GU; 60°: 0 - 1,000GU; 85°:0 - 160GU
Repetabilitate: ± 0.1GU (0 - 10GU); ±0.2GU (10 - 100GU); ±0.2%: 100 - 2000GU
Reproductibilitate: ± 0.2GU (0 - 10GU); ±0.5GU (10 - 100GU); ±0.5% 100 - 2000GU
Rezolutie
Luciu: 0.1 GU (0 - 100GU); 1 GU (>100GU)
% Reflectie: 0.01% (0 - 10GU); 0.1% (10 - 100GU)
Umbra: 0.1 HU (0 - 100HU); 1 HU (>100HU) Temperatura de operare: -10°C to 50°C / Umiditate 0 - 85%RH fara condens
Dimensiune (H x W x D): 68 x 155 x 50mm
Greutate: 534g cu baterie
Se livreaza cu: Instrument Elcometer 480, bloc integrat de calibrare, certificat de calibrare, baterie 2 x AA, curea de mână, manual de operare, plastic jeanta transport, program software ElcoMaster si cablu USB

Elcometer 480 Single, Dual & Triple Angle Glossmeter combines highly accurate, repeatable and reproducible measurements with industry leading inter-instrument agreement - across the Elcometer 480 Glossmeter’s entire 0-2,000GU range.

Technical Data
Display: 2.4'' (6cm) QVGA colour TFT display, 320 x 240 pixels
Power: USB (via PC) or 2 x AA batteries (~50,000 readings)
Measurement Dimensions: 20°: 10 x 10mm; 60°: 8 x 16mm; 85°: 4 x 55mm
Measurement Range 20°: 0 - 2,000GU; 60°: 0 - 1,000GU; 85°:0 - 160GU
Repeatability ± 0.1GU (0 - 10GU); ±0.2GU (10 - 100GU); ±0.2%: 100 - 2000GU
Reproducibility ± 0.2GU (0 - 10GU); ±0.5GU (10 - 100GU); ±0.5% 100 - 2000GU
Resolution
Gloss: 0.1 GU (0 - 100GU); 1 GU (>100GU)
% Reflectance: 0.01% (0 - 10GU); 0.1% (10 - 100GU)
Haze: 0.1 HU (0 - 100HU); 1 HU (>100HU)
Operating Temperature -10°C to 50°C; Relative Humidity: 0 - 85%RH
Dimensions: (H x W x D) 68 x 155 x 50mm
Weight: 534g including batteries
Packing List: Elcometer 480 Glossmeter, integrated calibration tile, calibration certificate, 2 x AA batteries, wrist strap, operating instructions, plastic carry case, ElcoMaster® software (Model T) and USB cable (Model T)



Glosmetru economic portabil
Model SA0833

Aparat universal economic pentru inspectie stralucirea cu o geometrie de masurare 20° 60° 85° pentru suprafete cu luciu mic, mediu si mare

Universal 3 Angles Glossmeter


produsul poate fi achizitionat si prin SEAP


Solicit oferta personalizata »

• Geometrie de masurare: 20°±0,1°, 60° ±0,1° si 85°±0,1°
• Abatere axa receptor/imagine reflectata : ±0,1°
• Domeniu de masura: 0~199,9 GU
• Rezolutie: 0,1 GU
• Acuratete: ±1.5 GU
• Repetabilitate: ±0.4 GU
• Calibrare: automata
• Sursa iluminare: A
• Afisare: display LCD
• Senzor de detectie: fotodiode siliconice
• Zona mica de masurare: 11x54mm
• Suprafata masurata: 20°=10x10mm / 65°=10x20mm / 80°=7x24mm
• Alimentare: baterie 1 AA
• Dimensiuni: 142x32x64 mm
• Greutate: 320 g (fara baterie)

Complying with standards: ISO2813, ISO7668, ASTMD523, ASTM D2457, DIN67530, GB/T9754, GB/T13891, GB/T8807, GB/T7706
Universal Glossmeter used for measurement on flat surfaces and operate like a refractometer.
Compact dimensions 3 corners lamp geometry and high accuracy make it the ideal instruments for quality control in production line or off-site.
Calibration is performed in seconds thanks to the master supplied.
The 3 detection geometries (20 °, 60°, 85°) allow maximum flexibility of use,including low,medium and high brightness surfaces.
Calibration report on instrument or on calibration master upon request

Applications
Gloss measurement on ink prints , paint, wax, and processed wood coatings
Gloss measurement on marble, granite, glass, glass blocks, etc.
Gloss measurement on plastics and sheets
